IAP-3600BE-4PF Точка доступа Wi-Fi 7 802.11be промышленная, 4 порта PoE 10/100/1000 Мб/с, 1 порт RJ45 10/100/1000 Мб/с, 1 порт SFP 1000 Мб/с

Physical Interfaces

4 x 10/100/1000BASE-T RJ45 LAN ports, auto-negotiation, auto MDI/MDI-X (Port 1 to Port 4)
4 x 10/100/1000BASE-T RJ45 LAN ports with 4-port IEEE 802.3at PoE+ injector function
1 x 10/100/1000BASE-T RJ45 WAN/LAN port, auto-negotiation, auto MDI/MDI-X (Port 5)
1 x 1000BASE-X SFP interface WAN/LAN port
2 x dual-band (2.4GHz/5GHz) RP-SMA connectors with antennas
1 USB 3.0 port for system configuration backup/upload and firmware upgrade
1 x reset button for system factory default and reboot


LAN Port

Hardware-based 10/100Mbps, half/full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation, and auto MDI/MDI-X
Features Store-and-Forward mode with wire-speed filtering and forwarding rates
IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
10K jumbo frame
Automatic address learning and address aging


Industrial Case and Installation

IP30 metal case protection
DIN rail or wall-mount design
DC 48-54V, redundant power with reverse polarity protection
-40 to 70 degrees C operating temperature


Digital Input and Digital Output

2 Digital Input (DI)
2 Digital Output (DO)
Integrate sensors into auto alarm system


Multiple Operation Modes Options

Multiple operation modes: AP/Repeater mode, WISP mode and Gateway mode options


Industrial-Grade Wireless LAN Compliance

Supports Wi-Fi 7 (IEEE 802.11be), the latest generation of wireless networking technology
Backward compatible with 2.4GHz (802.11b/g/n/ax/be), 5GHz (802.11a/n/ac/ax/be) frequency bands


RF Interface Characteristics

802.11be 2T2R architecture with data rates up to 3600Mbps (688Mbps in 2.4GHz and 2882Mbps in 5GHz)
High output power with multi-level adjustable transmit power control


Secure Wireless Connection Features

Full encryption supported: WPA3 Personal,WPA2/WPA3 Personal,WPA2 Personal (AES) ,WPA2 Personal (TKIP),WPA2 Personal (TKIP+AES),WPA/WPA2 Personal (AES) ,WPA/WPA2 Personal (TKIP) , WPA/WPA2 Personal (TKIP+AES) , WPA2 Enterprise, WPA/WPA2 Enterprise
MAC-based Access Control Lists (ACL) for enhanced device-level security


Wireless AP Mode Features

Supports OFDMA (orthogonal frequency division multiple access)
Supports MU-MIMO (multi-user multiple-input multiple-output), Beamforming and BSS Coloring
WMM (Wi-Fi multimedia) provides higher priority to multimedia transmitting over wireless
Coverage threshold to limit the weak signal of clients occupying session
Real-time Wi-Fi channel analysis chart and client limit control for better performance
Terminal Seamless Roaming with 802.11k, 802.11v, and 802.11r
NEW: Supports Wi-Fi 7 enhancements, including:
4096-QAM for higher data rates
Multi-Link Operation (MLO) for simultaneous multi-band transmission


Gateway Mode Features

Built-in RADIUS server/Client
Captive Portal
UPnP
IP routing protocol supports RIPv1/v2, OSPF
PLANET DDNS/Easy DDNS
SPI firewall, DDoS block, system security and NAT ALGs
MAC address/IP/Web filtering and QoS
DMZ and port forwarding


Easy Deployment and Management

Supports PLANET AP Controllers in AP mode
Self-healing mechanism through system auto reboot setting
System status monitoring through remote syslog server
Gateway mode supports PLANET DDNS/Easy DDNS, Captive Portal, RADIUS Server/Client
PLANET Smart Discovery Utility for deployment management
PLANET NMS system and CloudViewer for deployment management


Power over Ethernet

Complies with IEEE 802.3at Power over Ethernet Plus, end-span PSE
Backward compatible with IEEE 802.3af Power over Ethernet
Up to 4 ports of IEEE 802.3af / 802.3at devices powered
Supports PoE power up to 36 watts for each PoE port
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
PoE management
Total PoE power budget control
Per port PoE function enable/disable
PoE port power feeding priority
Per PoE port power limitation
PD classification detection
PD alive check
